仕様
Overview
Interface
PCIe Gen4x4, NVMe 1.4
Flash Technology
3D TLC
Capacity
480GB～1.9TB
Form Factor
2.5 inch (7mm)
Dimensions
100.5 x 70.0 x 7.0 mm
DRAM
No
Performance
Seq. Performance Read (max.)
4,750 MB/s
Seq. Performance Write (max.)
4,370 MB/s
Random 4K Read (IOPS max.)
804,890
Random 4K Write (IOPS max.)
705,636
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1.9TB: 4,815 TB
960GB: 2,408 TB
480GB: 1,204 TB
960GB: 2,408 TB
480GB: 1,204 TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G p-p, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 12V
Power Operation (max.)
650 mA
Power Idle / Standby
530 mA
Key Features
Power Failure Protection (PFP)
●
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
FWxpress
●
Warranty
Warranty
3 years within TBW
