仕様
Overview
Interface
SATA III/6.0Gbps
Flash Technology
SLC
Capacity
8GB ~ 64GB
Form Factor
M.2 2280 (B+M key)
Dimensions
80.0 x 22.0 x 3.5
DRAM
Yes
Performance
Seq. Performance Read (max.)
175 MB/s
Seq. Performance Write (max.)
165 MB/s
Random 4K Read (IOPS max.)
45,000
Random 4K Write (IOPS max.)
20,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
60,000
TBW
64GB: 1,388 TB
32GB: 694 TB
16GB: 347 TB
8GB: 173 TB
32GB: 694 TB
16GB: 347 TB
8GB: 173 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C ～ 95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
15G, 10 ～ 2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
500 mA
Power Idle / Standby
95 mA
Key Features
Advanced Power Shield
●
AES-256
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 8GB | -20～75°C | SP008GIMDC701SV0 |
| 16GB | -20～75°C | SP016GIMDC701SV0 |
| 32GB | -20～75°C | SP032GIMDC701SV0 |
| 64GB | -20～75°C | SP064GIMDC701SV0 |
