仕様
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
64GB～1TB
Form Factor
M.2 2260 (B+M key)
Dimensions
60.0 x 22.0 x 3.5 mm
DRAM
Yes
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
78,000
Random 4K Write (IOPS max.)
86,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1TB: 3,000 TB
512GB: 1,500 TB
256GB: 750 TB
128GB: 375 TB
64GB: 187 TB
512GB: 1,500 TB
256GB: 750 TB
128GB: 375 TB
64GB: 187 TB
Operating Environment
Operating Temperature
-20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
580 mA
Power Idle / Standby
110 mA
Key Features
Advanced Power Shield
●
TCG Opal 2.0
◎
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 32GB | -20～75°C | SP032GIMDB355SV0 |
| 64GB | -20～75°C | SP064GIMDB355SV0 |
| 64GB | -55°C～95°C | SP064GIMDB355SW0 |
| 128GB | -20～75°C | SP128GIMDB355SV0 |
| 128GB | -55°C～95°C | SP128GIMDB355SW0 |
| 256GB | -20～75°C | SP256GIMDB355SV0 |
| 256GB | -55°C～95°C | SP256GIMDB355SW0 |
| 512GB | -20～75°C | SP512GIMDB355SV0 |
| 512GB | -55°C～95°C | SP512GIMDB355SW0 |
| 1TB | -20～75°C | SP010TIMDB355SV0 |
| 1TB | -55°C～95°C | SP010TIMDB355SW0 |
