仕様
Overview
Interface
SATA III/6.0Gbps
Flash Technology
TLC
Capacity
64GB～2TB
Form Factor
2.5 inch (7mm)
Dimensions
100.4 x 69.9 x 6.8 mm
DRAM
No
Performance
Seq. Performance Read (max.)
540 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
29,000
Random 4K Write (IOPS max.)
85,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
2TB: 4,419TB
1TB: 2,209 TB
512GB: 1,105 TB
256GB: 551TB
128GB: 276 TB
1TB: 2,209 TB
512GB: 1,105 TB
256GB: 551TB
128GB: 276 TB
Operating Environment
Operating Temperature
-20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
340 mA
Power Idle / Standby
85 mA
Key Features
Advanced Power Shield
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
DAP
●
FWxpress
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 64GB | -20 ~ 75℃ | SP064GICSD3K5EV0 |
| 128GB | -20 ~ 75℃ | SP128GICSD3K5EV0 |
| 256GB | -20 ~ 75℃ | SP256GICSD3K5EV0 |
| 512GB | -20 ~ 75℃ | SP512GICSD3K5EV0 |
| 1TB | -20 ~ 75℃ | SP010TICSD3K5EV0 |
