仕様
Overview
Interface
CFast 2.0/SATA III/6.0Gbps
Flash Technology
SLC
Capacity
16GB～64GB
Form Factor
CFast
Dimensions
36.4 x 42.8 x 3.6 mm
Performance
Seq. Performance Read (max.)
440 MB/s
Seq. Performance Write (max.)
360 MB/s
Random 4K Read (IOPS max.)
29,000
MTBF
>3,000,000 hrs
P/Eサイクル
60,000
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
400 mA
Power Consumption (idle)
110 mA
Key Features
S.M.A.R.T
●
AES-256
●
Write Protect
◎
Thermal Throttling
●
DEVSLP/ TRIM
●
Advanced Power Shield
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 4GB | -20℃ ~ 75℃ | SP004GICFX711NV0 |
| 4GB | -40℃ ~ 85℃ | SP004GICFX711NW0 |
| 8GB | -20℃ ~ 75℃ | SP008GICFX711NV0 |
| 8GB | -40℃ ~ 85℃ | SP008GICFX711NW0 |
| 16GB | -20℃ ~ 75℃ | SP016GICFX711NV0 |
| 16GB | -40℃ ~ 85℃ | SP016GICFX711NW0 |
| 32GB | -20℃ ~ 75℃ | SP032GICFX711NV0 |
| 32GB | -40℃ ~ 85℃ | SP032GICFX711NW0 |
