规格
Overview
Interface
USB 2.0
Flash Technology
SLC
Capacity
512MB～8GB
Form Factor
UFB Driver
Dimensions
60.6 x 18.0 x 8.1 mm
Performance
Seq. Performance Read (max.)
20 MB/s
Seq. Performance Write (max.)
18 MB/s
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
60,000
Duration (cycles)
10,000
Operating Environment
Operating Temperature
-20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Consumption (max.)
200mA
Power Consumption (idle)
75mA
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 512MB | -20 ~ 75℃ | SP512MIUFD711NV0 |
| 1GB | -20 ~ 75℃ | SP001GIUFD711NV0 |
| 2GB | -20 ~ 75℃ | SP002GIUFD711NV0 |
| 4GB | -20 ~ 75℃ | SP004GIUFD711NV0 |
| 8GB | -20 ~ 75℃ | SP008GIUFD711NV0 |
| 512MB | -40 ~ 85℃ | SP512MIUFD711NW0 |
| 1GB | -40 ~ 85℃ | SP001GIUFD711NW0 |
| 2GB | -40 ~ 85℃ | SP002GIUFD711NW0 |
| 4GB | -40 ~ 85℃ | SP004GIUFD711NW0 |
| 8GB | -40 ~ 85℃ | SP008GIUFD711NW0 |
