规格
Overview
Interface
PCIe Gen3x4 NVMe 1.3
Flash Technology
3D TLC
Capacity
480GB～7.6TB
Form Factor
2.5 inch (7mm)
Dimensions
100.00 x 69.85 x 7.00 mm
DRAM
Yes
Performance
Seq. Performance Read (max.)
3,300 MB/s
Seq. Performance Write (max.)
900 MB/s
Random 4K Read (IOPS max.)
832,000
Random 4K Write (IOPS max.)
206,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
7.6TB: 12,500 TB
3.8TB: 6,000TB
3.8TB: 6,000TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 80～2000Hz
Drop
80cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 12V
Power Operation (max.)
583 mA
Power Idle / Standby
191 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 480GB | -40°C～85°C | SP480GISSU3F5SW0 |
| 960GB | -40°C～85°C | SP960GISSU3F5SW0 |
| 1.9TB | -40°C～85°C | SP019TISSU3F5SW0 |
| 3.8TB | -40°C～85°C | SP038TISSU3F5SW0 |
| 7.6TB | -40°C～85°C | SP076TISSU3F5SW0 |
