规格
Overview
Interface
SATA III/6.0Gbps
Flash Technology
pSLC
Capacity
16GB ~ 512GB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
DRAM
Yes
Performance
Seq. Performance Read (max.)
520 MB/s
Seq. Performance Write (max.)
300 MB/s
Random 4K Read (IOPS max.)
79,000
Random 4K Write (IOPS max.)
73,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
20,000
TBW
512GB: 9,203 TB
256GB: 4,601 TB
128GB: 2,301 TB
64GB: 1,151 TB
32GB: 560 TB
16GB: 289 TB
256GB: 4,601 TB
128GB: 2,301 TB
64GB: 1,151 TB
32GB: 560 TB
16GB: 289 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10 ～ 2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
790 mA
Power Idle / Standby
90mA
Key Features
Power Failure Protection (PFP)
●
Advanced Power Shield
●
End-to-End Data Protection
●
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 16GB | -20 ~ 75℃ | SP016GISSD501RV0 |
| 32GB | -20 ~ 75℃ | SP032GISSD501RV0 |
| 64GB | -20 ~ 75℃ | SP064GISSD501RV0 |
| 128GB | -20 ~ 75℃ | SP128ISSD501RV0 |
| 256GB | -20 ~ 75℃ | SP256GISSD501RV0 |
| 512GB | -20 ~ 75℃ | SP512GISSD501RV0 |
| 16GB | -40 ~ 85℃ | SP016GISSD501RW0 |
| 32GB | -40 ~ 85℃ | SP032GISSD501RW0 |
| 64GB | -40 ~ 85℃ | SP064GISSD501RW0 |
| 128GB | -40 ~ 85℃ | SP128ISSD501RW0 |
| 256GB | -40 ~ 85℃ | SP256GISSD501RW0 |
| 512GB | -40 ~ 85℃ | SP512GISSD501RW0 |
