规格
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
64GB～2TB
Form Factor
mSATA (MO-300)
Dimensions
51.0 x 30.0 x 3.5 mm
DRAM
No
Performance
Seq. Performance Read (max.)
545 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
49,000
Random 4K Write (IOPS max.)
75,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
2TB: 4,419TB
1TB: 2,209TB
512GB: 1,105TB
256GB: 551TB
128GB: 276TB
64GB: 139TB
1TB: 2,209TB
512GB: 1,105TB
256GB: 551TB
128GB: 276TB
64GB: 139TB
Operating Environment
Operating Temperature
-20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
255 mA
Power Idle / Standby
70 mA
Key Features
Advanced Power Shield
●
AES-256
●
Thermal Throttling
●
DEVSLP
◎
S.M.A.R.T
●
Write Protect
◎
Quick Erase
◎
DAP
●
FWxpress
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 32GB | -20 ~ 75℃ | SP032GIMSA3K5EV0 |
| 64GB | -20 ~ 75℃ | SP064GIMSA3K5EV0 |
| 128GB | -20 ~ 75℃ | SP128GIMSA3K5EV0 |
| 256GB | -20 ~ 75℃ | SP256GIMSA3K5EV0 |
| 512GB | -20 ~ 75℃ | SP512GIMSA3K5EV0 |
| 1TB | -20 ~ 75℃ | SP010TIMSA3K5EV0 |
| 2TB | -20 ~ 75℃ | SP020TIMSA3K5EV0 |
