规格
Overview
Interface
CF 6.0
Flash Technology
pSLC
Capacity
4GB～64GB
Form Factor
CF Card
Dimensions
42.8 x 36.4 x 3.3 mm
Performance
Seq. Performance Read (max.)
115 MB/s
Seq. Performance Write (max.)
90 MB/s
MTBF
>3,000,000 hrs
P/E Cycle
20,000
Operating Environment
Operating Temperature
-20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V or DC 5.0V
Power Consumption (max.)
360 mA
Power Consumption (idle)
300 mA
Key Features
S.M.A.R.T
●
Advanced Power Shield
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 4GB | -20 ~ 75℃ | SP004GICFI525NV0 |
| 8GB | -20 ~ 75℃ | SP008GICFI525NV0 |
| 16GB | -20 ~ 75℃ | SP016GICFI525NV0 |
| 32GB | -20 ~ 75℃ | SP032GICFI525NV0 |
| 64GB | -20 ~ 75℃ | SP064GICFI525NV0 |
