规格
Overview
Interface
CF 4.1
Flash Technology
SLC
Capacity
128MB～1GB
Form Factor
CF Card
Dimensions
42.8 x 36.4 x 3.3 mm
Performance
Seq. Performance Read (max.)
65 MB/s
Seq. Performance Write (max.)
54 MB/s
MTBF
>3,000,000 hrs
P/E Cycle
60,000
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
CFI000V6/ CFI000W6
CFI000V6/ CFI000W6
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V or DC 5.0V
Power Consumption (max.)
180 mA
Power Consumption (idle)
2 mA
Key Features
S.M.A.R.T
●
Write Protect
◎
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 128MB | -20 ~ 75℃ | SP128MBCFI000V601T |
| 256MB | -20 ~ 75℃ | SP256MBCFI000V601T |
| 512MB | -20 ~ 75℃ | SP512MBCFI000V601T |
| 1GB | -20 ~ 75℃ | SP001GBCFI000V601T |
| 128MB | -40 ~ 85℃ | SP128MBCFI000W601T |
| 256MB | -40 ~ 85℃ | SP256MBCFI000W601T |
| 512MB | -40 ~ 85℃ | SP512MBCFI000W601T |
| 1GB | -40 ~ 85℃ | SP001GBCFI000W601T |
