SPECIFICATIONS
Overview
Interface
PCIe Gen5x4, NVMe v2.0c
Flash Technology
3D eTLC
Capacity
3.2TB～15.36TB
Form Factor
U.2 15mm
Dimensions
100.2 x 69.85 x 14.8
DRAM
External DRAM
Performance
Seq. Performance Read (max.)
14,600 MB/s
Seq. Performance Write (max.)
11,300 MB/s
Random 4K Read (IOPS max.)
3,500,000
Random 4K Write (IOPS max.)
1,100,000
UBER
10-17
Data Retention
3 months @ 40℃ (EOL)
MTBF @ 25°C
2Mhrs
DWPD = 1
3.84TB
7.68TB
15.36TB
7.68TB
15.36TB
DWPD = 3
3.2TB
6.4TB
12.8TB
6.4TB
12.8TB
Operating Environment
Operating Temperature
0°C～70°C
Storage Temperature
-40°C～85°C
Operating Humidity
5%～95%
Vibration
3.13 G, 5 ~ 800Hz
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 12V
Power Consumption (max.)
24.1W
Power Consumption (idle)
5W
Key Features
Power Failure Protection (PFP)
●
End-to-End Data Protection
●
Thermal Throttling
●
S.M.A.R.T
●
FWxpress
●
Warranty
Warranty
5 years
