SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D eTLC
Capacity
480GB～7.68TB
Form Factor
2.5 inch (7mm)
Dimensions
100.0 x 69.85 x 6.9
DRAM
External DRAM
Performance
Seq. Performance Read (max.)
530 MB/s
Seq. Performance Write (max.)
510 MB/s
Random 4K Read (IOPS max.)
85,000
Random 4K Write (IOPS max.)
78,000
UBER
10⁻¹⁷
Data Retention
3 months @ 40℃ (EOL)
MTBF @ 25°C
2Mhrs
DWPD = 1
480GB
960GB
1.92TB
3.84TB
7.68TB
960GB
1.92TB
3.84TB
7.68TB
DWPD = 3
480GB
960GB
1.92TB
3.84TB
960GB
1.92TB
3.84TB
Operating Environment
Operating Temperature
0°C～70°C
Storage Temperature
-40°C～85°C
Operating Humidity
5%～95%
Vibration
3.13 G, 5 ~ 800Hz
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5V
Power Consumption (max.)
4.5W
Power Consumption (idle)
1.6W
Key Features
Power Failure Protection (PFP)
●
End-to-End Data Protection
●
TCG Opal 2.01
●
AES-256
●
Thermal Throttling
●
S.M.A.R.T
●
FWxpress
●
Warranty
Warranty
5 years
