SPECIFICATIONS
Overview
Interface
PCIe Gen4x4, NVMe v1.4c
Flash Technology
3D eTLC
Capacity
480GB～1.92TB
Form Factor
M.2 2280 (M key)
Dimensions
80 x 22 x 4.1
DRAM
External DRAM
Performance
Seq. Performance Read (max.)
3,400 MB/s
Seq. Performance Write (max.)
1,400 MB/s
Random 4K Read (IOPS max.)
630,000
Random 4K Write (IOPS max.)
90,000
UBER
10-17
Data Retention
3 months @ 40℃ (EOL)
MTBF @ 25°C
2Mhrs
DWPD = 1
480GB
960GB
1,920GB
960GB
1,920GB
Operating Environment
Operating Temperature
0°C～70°C
Storage Temperature
-40°C～85°C
Operating Humidity
5%～95%
Vibration
3.13 G, 5 ~ 800Hz
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
5.5W
Power Consumption (idle)
2.5W
Key Features
Power Failure Protection (PFP)
●
End-to-End Data Protection
●
Thermal Throttling
●
S.M.A.R.T
●
FWxpress
●
Warranty
Warranty
5 years
