SPECIFICATIONS
Overview
Interface
PCIe Gen5x4, NVMe v2.0c
Flash Technology
3D eTLC
Capacity
1.6TB～7.68TB
Form Factor
E1.S 9.5mm / 15mm
Dimensions
118.75 x 33.75 x 15.0
DRAM
External DRAM
Performance
Seq. Performance Read (max.)
13,500 MB/s
Seq. Performance Write (max.)
10,400 MB/s
Random 4K Read (IOPS max.)
3,200,000
Random 4K Write (IOPS max.)
870,000
UBER
10-17
Data Retention
3 months @ 40℃ (EOL)
MTBF @ 25°C
2Mhrs
DWPD = 1
1.92TB
3.84TB
7.68TB
3.84TB
7.68TB
DWPD = 3
1.6TB
3.2TB
6.4TB
3.2TB
6.4TB
Operating Environment
Operating Temperature
0°C～70°C
Storage Temperature
-40°C～85°C
Operating Humidity
5%～95%
Vibration
20 G, 20 ~ 2000Hz
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 12V
Power Consumption (max.)
23 W
Power Consumption (idle)
5 W
Key Features
Power Failure Protection (PFP)
●
End-to-End Data Protection
●
TCG Opal 2.01
●
AES-256
●
Thermal Throttling
●
S.M.A.R.T
●
FWxpress
●
Warranty
Warranty
5 years
