SPEZIFIKATIONEN
Overview
Interface
CFast 2.0/SATA III/6.0Gbps
Flash Technology
pSLC (3D TLC)
Capacity
32GB～256GB
Form Factor
CFast
Dimensions
36.4 x 42.8 x 3.6 mm
Performance
Seq. Performance Read (max.)
560MB/s
Seq. Performance Write (max.)
510 MB/s
Random 4K Read (IOPS max.)
91,000
Random 4K Write (IOPS max.)
81000
MTBF
>3,000,000 hrs
P/E Cycle
60,000
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
480 mA
Power Consumption (idle)
80 mA
Key Features
S.M.A.R.T
●
AES-256
●
Write Protect
◎
Thermal Throttling
●
DEVSLP/ TRIM
●
Advanced Power Shield
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 32GB | -20℃ ~ 75℃ | SP032GICFX5M5NV0 |
| 64GB | -20℃ ~ 75℃ | SP064GICFX5M5NV0 |
| 128GB | -20℃ ~ 75℃ | SP128GICFX5M5NV0 |
