規格
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
3.8TB～7.6TB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
550 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
98,000
Random 4K Write (IOPS max.)
88,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
7,680GB: 14,000 TB
3,840GB: 7,000 TB
3,840GB: 7,000 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G (Peak-to-Peak), 80～2000 Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
600 mA
Power Idle / Standby
240 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
◎
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 240GB | -20 ~ 75℃ | SP240GISSD3F5SV0 |
| 256GB | -20 ~ 75℃ | SP256GISSD3F5SV0 |
| 480GB | -20 ~ 75℃ | SP480GISSD3F5SV0 |
| 512GB | -20 ~ 75℃ | SP512GISSD3F5SV0 |
| 960GB | -20 ~ 75℃ | SP960GISSD3F5SV0 |
| 1.9TB | -20 ~ 75℃ | SP019TISSD3F5SV0 |
| 2TB | -20 ~ 75℃ | SP020TISSD3F5SV0 |
| 3.8TB | -20 ~ 75℃ | SP038TISSD3F5SV0 |
| 7.6TB | -20 ~ 75℃ | SP076TISSD3F5SV0 |
