規格
Overview
Interface
SD 3.0 / UHS-I
Flash Technology
SLC
Capacity
1GB～8GB
Form Factor
SD Card
Dimensions
32.0 x 24.0 x 2.1 mm
Performance
Seq. Performance Read (max.)
40 MB/s
Seq. Performance Write (max.)
30 MB/s
Random 4K Read (IOPS max.)
10,000
MTBF
>3,000,000 hrs
P/E Cycle
60,000
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-40°C～85°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
30G, 10～2000Hz
Drop
150cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
65 mA
Power Consumption (idle)
140 uA
Key Features
AES-256
●
Write Protect
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 512MB | -40℃ ~ 85℃ | SP512MISDI731NW0 |
| 1GB | -40℃ ~ 85℃ | SP001GISDI731NW0 |
| 1GB | -40℃ ~ 85℃ | SP001GISDI732NW0 |
| 2GB | -40℃ ~ 85℃ | SP002GISDI731NW0 |
| 2GB | -40℃ ~ 85℃ | SP002GISDI732NW0 |
| 4GB | -40℃ ~ 85℃ | SP004GISDI731NW0 |
| 4GB | -40℃ ~ 85℃ | SP004GISDI732NW0 |
| 8GB | -40℃ ~ 85℃ | SP008GISDI731NW0 |
| 8GB | -40℃ ~ 85℃ | SP008GISDI732NW0 |
