規格
Overview
Interface
SATA III/6.0Gbps
Flash Technology
TLC
Capacity
64GB～1TB
Form Factor
mSATA (MO-300)
Dimensions
51.0 x 30.0 x 3.5 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
78,000
Random 4K Write (IOPS max.)
60,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1TB: 3,000 TB 512GB: 1,500 TB 256GB: 750 TB 128GB: 375 TB 64GB: 187 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
650 mA
Power Idle / Standby
170 mA
Key Features
Advanced Power Shield
●
TCG Opal 2.0
◎
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
FWxpress
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 32GB | -20 ~ 75℃ | SP032GIMSA355SV0 |
| 64GB | -20 ~ 75℃ | SP064GIMSA355SV0 |
| 64GB | -40 ~ 85℃ | SP064GIMSA351SW0 |
| 128GB | -20 ~ 75℃ | SP128GIMSA355SV0 |
| 128GB | -40 ~ 85℃ | SP128GIMSA351SW0 |
| 256GB | -20 ~ 75℃ | SP256GIMSA355SV0 |
| 256GB | -40 ~ 85℃ | SP256GIMSA351SW0 |
| 512GB | -20 ~ 75℃ | SP512GIMSA355SV0 |
| 512GB | -40 ~ 85℃ | SP512GIMSA355SW0 |
| 512GB | -40 ~ 85℃ | SP512GIMSA351SW0 |
| 1TB | -20 ~ 75℃ | SP010TIMSA355SV0 |
| 1TB | -40 ~ 85℃ | SP010TIMSA351SW0 |
