規格
Overview
Interface
PCIe Gen3x1, NVMe 1.4
Flash Technology
TLC
Capacity
64GB～512GB
Form Factor
M.2 2230 (E key)
Dimensions
30.0 x 22.0 x 3.5 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
890 MB/s
Seq. Performance Write (max.)
880 MB/s
Random 4K Read (IOPS max.)
140,000
Random 4K Write (IOPS max.)
200,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3000
TBW
1TB: 2,488 TB
512GB: 1,233 TB
256GB: 615 TB
128GB: 307 TB
64GB: 154 TB
512GB: 1,233 TB
256GB: 615 TB
128GB: 307 TB
64GB: 154 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
1420 mA
Power Idle / Standby
130 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
DAP
●
FWxpress
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 64GB | -20℃ ~ 75℃ |
SP064GIMEM3K5EVE |
| 64GB | -40℃ ~ 85℃ |
SP064GIMEM3K5EWE |
| 128GB | -20℃ ~ 75℃ |
SP128GIMEM3K5EVE |
| 128GB | -40℃ ~ 85℃ | SP128GIMEM3K5EWE |
| 256GB | -20℃ ~ 75℃ |
SP256GIMEM3K5EVE |
| 256GB | -40℃ ~ 85℃ | SP256GIMEM3K5EWE |
| 512GB | -20℃ ~ 75℃ |
SP512GIMEM3K5EVE |
| 512GB | -40℃ ~ 85℃ | SP512GIMEM3K5EWE |
