SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
SLC
Capacity
16GB ~ 128GB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
190 MB/s
Seq. Performance Write (max.)
180 MB/s
Random 4K Read (IOPS max.)
45,000
Random 4K Write (IOPS max.)
20,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
60,000
TBW
256GB: 14,819 TB
128GB: 7,409 TB
64GB: 3,705 TB
32GB: 1,852 TB
16GB: 926 TB
128GB: 7,409 TB
64GB: 3,705 TB
32GB: 1,852 TB
16GB: 926 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10 ～ 2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
295 mA
Power Idle / Standby
90mA
Key Features
Power Failure Protection (PFP)
●
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 16GB | -20 ~ 75℃ | SP016GISSD701RV0 |
| 16GB | -40 ~ 85℃ | SP016GISSD701RW0 |
| 32GB | -20 ~ 75℃ | SP032GISSD701RV0 |
| 32GB | -40 ~ 85℃ | SP032GISSD701RW0 |
| 64GB | -20 ~ 75℃ | SP64GISSD701RV0 |
| 64GB | -40 ~ 85℃ | SP064GISSD701RW0 |
| 128GB | -20 ~ 75℃ | SP128GISSD701RV0 |
| 128GB | -40 ~ 85℃ | SP128GISSD701RW0 |
