SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
TLC
Capacity
256GB～4TB
Form Factor
2.5 inch (7mm)
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
550 MB/s
Seq. Performance Write (max.)
530 MB/s
Random 4K Read (IOPS max.)
98,000
Random 4K Write (IOPS max.)
89,000
MTBF @ 25°C
>1,600,000 hrs
P/E Cycle
3,000
TBW
4TB: 6,700 TB
2TB: 3,040 TB
1TB: 1,420 TB
512GB: 650 TB
256GB: 270 TB
2TB: 3,040 TB
1TB: 1,420 TB
512GB: 650 TB
256GB: 270 TB
Operating Environment
Operating Temperature
0°C～70°C
Storage Temperature
-40°C～85°C
Operating Humidity
0%～90%
(40°C Max. Wet Bulb Temp)
(40°C Max. Wet Bulb Temp)
Vibration
20G p-p, 80～2000Hz
Drop
80cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
460 mA
Power Idle / Standby
420 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 256GB | 0 ~ 70°C | SP256GISSD3F1FV0 |
| 512GB | 0 ~ 70°C | SP512GISSD3F1FV0 |
| 1TB | 0 ~ 70°C | SP010TISSD3F1FV0 |
| 2TB | 0 ~ 70°C | SP020TISSD3F1FV0 |
| 4TB | 0 ~ 70°C | SP040TISSD3F1FV0 |
