SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
TLC
Capacity
128GB～2TB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
95,000
Random 4K Write (IOPS max.)
91,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
2TB: 5,486 TB
1TB: 2,743 TB
512GB: 1,372 TB
256GB: 686 TB
128GB: 343 TB
1TB: 2,743 TB
512GB: 1,372 TB
256GB: 686 TB
128GB: 343 TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
700 mA
Power Idle / Standby
110 mA
Key Features
Power Failure Protection (PFP)
●
Advanced Power Shield
●
End-to-End Data Protection
◎
TCG Opal 2.0
◎
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 128GB | -20 ~ 75℃ | SP128GISSD355RV0 |
| 512GB | -20 ~ 75℃ | SP512GISSD355RV0 |
| 960GB | -20 ~ 75℃ | SP960GISSD355RV0 |
| 128GB | -40 ~ 85℃ | SP128GISSD351RW0 |
| 256GB | -40 ~ 85℃ | SP256GISSD351RW0 |
| 512GB | -40 ~ 85℃ | SP512GISSD351RW0 |
| 010TB | -40 ~ 85℃ | SP010TISSD351RW0 |
| 020TB | -40 ~ 85℃ | SP020TISSD351RW0 |
| 128GB | -40 ~ 85℃ | SP128GISSD355RW0 |
| 256GB | -40 ~ 85℃ | SP256GISSD355RW0 |
| 512GB | -40 ~ 85℃ | SP512GISSD355RW0 |
| 010TB | -40 ~ 85℃ | SP010TISSD355RW0 |
| 020TB | -40 ~ 85℃ | SP020TISSD355RW0 |
