SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
MLC
Capacity
32GB～1TB
Form Factor
2.5 inch
Dimensions
100.4 x 69.9 x 6.8 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
520 MB/s
Seq. Performance Write (max.)
450 MB/s
Random 4K Read (IOPS max.)
79,000
Random 4K Write (IOPS max.)
73,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1TB: 2,761 TB
512GB: 1,380TB
256GB: 690 TB
128GB: 345 TB
64GB: 173 TB
32GB: 84 TB
512GB: 1,380TB
256GB: 690 TB
128GB: 345 TB
64GB: 173 TB
32GB: 84 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 5.0V
Power Operation (max.)
790 mA
Power Idle / Standby
90mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 64GB | -20 ~ 75℃ | SP064GISSD301SV0 |
| 128GB | -20 ~ 75℃ | SP128GISSD301SV0 |
| 1TB | -20 ~ 75℃ | SP010TISSD301SV0 |
| 64GB | -40 ~ 85℃ | SP064GISSD301SW0 |
| 128GB | -40 ~ 85℃ | SP128GISSD301SW0 |
| 1TB | -40 ~ 85℃ | SP010TISSD301SW0 |
| 32GB | -20 ~ 75℃ | SP032GISSD305SV0 |
| 64GB | -20 ~ 75℃ | SP064GISSD305SV0 |
| 128GB | -20 ~ 75℃ | SP128GISSD305SV0 |
| 256GB | -20 ~ 75℃ | SP256GISSD305SV0 |
| 480GB | -20 ~ 75℃ | SP480GISSD305SV0 |
| 512GB | -20 ~ 75℃ | SP512GISSD305SV0 |
| 128GB | -40 ~ 85℃ | SP128GISSD305SW0 |
