SPECIFICATIONS
Overview
Interface
SD 3.0 / UHS-I
Flash Technology
3D TLC
Capacity
32GB～256GB
Form Factor
SD Card
Dimensions
32.0 x 24.0 x 2.1 mm
Performance
Seq. Performance Read (max.)
93 MB/s
Seq. Performance Write (max.)
80 MB/s
Random 4K Read (IOPS max.)
10,000
MTBF
>3,000,000 hrs
P/E Cycle
3,000
Operating Environment
Operating Temperature
-25°C～85°C
Storage Temperature
-40°C～85°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
150cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
100 mA
Power Consumption (idle)
300 uA
Key Features
AES-256
●
Write Protect
●
TCG Opal 2.0
◎
Thermal Throttling
◎
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 32GB | -25 ~ 85℃ | SP032GISDI3R5NE0 |
| 64GB | -25 ~ 85℃ | SP064GISDI3R5NE0 |
| 128GB | -25 ~ 85℃ | SP128GISDI3R5NE0 |
| 256GB | -25 ~ 85℃ | SP256GISDI3R5NE0 |
| 512GB | -25 ~ 85℃ | SP512GISDI3R5NE0 |
