SPECIFICATIONS
Overview
Interface
Type C USB 3.2 Gen2
Flash Technology
TLC
Capacity
1TB, 2TB
Form Factor
Portable SSD
Dimensions
107.0 x 28.0 x 12 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
945 MB/s
Seq. Performance Write (max.)
945 MB/s
Random 4K Read (IOPS max.)
50,000
Random 4K Write (IOPS max.)
57,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
2TB: 5,354 TB
1TB: 2,639 TB
1TB: 2,639 TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G p-p, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
1650mA
Power Idle / Standby
220mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
Thermal Throttling
●
DEVSLP
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 1TB | -40 ~ 85°C | SP010TIPNV3M5EW0 |
| 2TB | -40 ~ 85°C | SP020TIPNV3M5EW0 |
