SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
pSLC (MLC)
Capacity
16GB～256GB
Form Factor
mSATA (MO-300)
Dimensions
51.0 x 30.0 x 3.5 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
380 MB/s
Random 4K Read (IOPS max.)
79,000
Random 4K Write (IOPS max.)
74,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
20,000
TBW
"256GB: 4,601 TB 128GB: 2,301 TB 64GB: 1,151 TB 32GB: 560 TB 16GB: 289 TB"
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
"10%～95% (30°C Max. Wet Bulb Temp)"
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
780 mA
Power Idle / Standby
95 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 16GB | -20 ~ 75℃ | SP016GIMSA505SV0 |
| 16GB | -40 ~ 85℃ | SP016GIMSA501SW0 |
| 64GB | -20 ~ 75℃ | SP064GIMSA505SV0 |
| 64GB | -40 ~ 85℃ | SP064GIMSA501SW0 |
| 128GB | -20 ~ 75℃ | SP128GIMSA505SV0 |
| 128GB | -40 ~ 85℃ | SP128GIMSA501SW0 |
| 256GB | -20 ~ 75℃ | SP256GIMSA505SV0 |
| 256GB | -40 ~ 85℃ | SP256GIMSA501SW0 |
