SPECIFICATIONS
Overview
Interface
PCIe Gen4x4, NVMe 2.0
Flash Technology
3D TLC
Capacity
128GB～2TB
Form Factor
M.2 2280 (M key)
Dimensions
80.0 x 22.0 x 3.5 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
4,600 MB/s
Seq. Performance Write (max.)
4,300 MB/s
Random 4K Read (IOPS max.)
845,000
Random 4K Write (IOPS max.)
644,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
2TB: 3,268 TB
1TB: 1,155 TB
512GB: 577 TB
256GB: 289 TB
128GB: 144 TB
1TB: 1,155 TB
512GB: 577 TB
256GB: 289 TB
128GB: 144 TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G p-p, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
1650mA
Power Idle / Standby
220mA
Key Features
Power Failure Protection (PFP)
●
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Write Protect
◎
Quick Erase
◎
DAP
●
FWxpress
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 128GB | -40℃ ~ 85℃ | SP128GIMEC3M5RW0 |
| 256GB | -40℃ ~ 85℃ | SP256GIMEC3M5RW0 |
| 512GB | -40℃ ~ 105℃ | SP512GIMEC3M5RW0 |
| 1TB | -40℃ ~ 105℃ | SP010TIMEC3M5RW0 |
| 2TB | -40℃ ~ 85℃ | SP020TIMEC3M5RW0 |
