SPECIFICATIONS
Overview
Interface
PCIe Gen3x4, NVMe 1.3
Flash Technology
3D TLC
Capacity
128GB～1TB
Form Factor
M.2 2280 (M key)
Dimensions
80.0 x 22.0 x 3.5
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
3,400 MB/s
Seq. Performance Write (max.)
2,900 MB/s
Random 4K Read (IOPS max.)
345,000
Random 4K Write (IOPS max.)
350,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1TB: 3,000 TB
512GB: 1500 TB
256GB: 750 TB
128GB: 375 TB
512GB: 1500 TB
256GB: 750 TB
128GB: 375 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
2450 mA
Power Idle / Standby
230 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
●
TCG Opal 2.0
◎
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 128GB | -20℃~ 75℃ | SP128GIMEC355SV0 |
| 240GB | -20℃~ 75℃ | SP240GIMEC355SV0 |
| 256GB | -20℃~ 75℃ | SP256GIMEC355SV0 |
| 480GB | -20℃~ 75℃ | SP480GIMEC355SV0 |
| 512GB | -20℃~ 75℃ | SP512GIMEC355SV0 |
| 1TB | -20℃~ 75℃ | SP010TIMEC355SV0 |
| 128GB | -40℃ ~ 85℃ | SP128GIMEC351SW0 |
| 256GB | -40℃ ~ 85℃ | SP256GIMEC351SW0 |
| 512GB | -40℃ ~ 85℃ | SP512GIMEC351SW0 |
| 1TB | -40℃ ~ 85℃ | SP010TIMEC351SW0 |
