SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
pSLC (3D TLC)
Capacity
32GB ~ 512GB
Form Factor
M.2 2280 (B+M key)
Dimensions
80.0 x 22.0 x 3.5 mm
External DRAM Buffer
Yes
Performance
Seq. Performance Read (max.)
560 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
94,000
Random 4K Write (IOPS max.)
89,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
30,000
TBW
512GB: 13,716 TB
256GB: 6,858 TB
128GB: 3,429 TB
64GB: 1,715 TB
32GB: 834 TB
256GB: 6,858 TB
128GB: 3,429 TB
64GB: 1,715 TB
32GB: 834 TB
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
750 mA
Power Idle / Standby
110 mA
Key Features
Advanced Power Shield
●
End-to-End Data Protection
◎
TCG Opal 2.0
◎
AES-256
◎
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 1TB | -20～75°C | SP010TIMDC555SV0 |
| 64GB | -20～75°C | SP064GIMDC555SV0 |
| 128GB | -20～75°C | SP128GIMDC555SV0 |
| 256GB | -20～75°C | SP256GIMDC555SV0 |
| 256GB | -40 ~ 85℃ | SP256GIMDC555SW0 |
