SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
64GB～1TB
Form Factor
M.2 2242 (B+M key)
Dimensions
42.0 x 22.0 x 3.5 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
540 MB/s
Seq. Performance Write (max.)
520 MB/s
Random 4K Read (IOPS max.)
29,000
Random 4K Write (IOPS max.)
84,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
3,000
TBW
1TB: 2,209TB
512GB: 1,105TB
256GB: 551TB
128GB: 276TB
64GB: 139TB
512GB: 1,105TB
256GB: 551TB
128GB: 276TB
64GB: 139TB
Operating Environment
Operating Temperature
-20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
460 mA
Power Idle / Standby
< 115mA
Key Features
Advanced Power Shield
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
Write Protect
◎
Quick Erase
◎
DAP
●
FWxpress
●
Warranty
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 1TB | -20～75°C | SP010TIMDA3K5EV0 |
| 32GB | -20～75°C | SP032GIMDA3K5EV0 |
| 64GB | -20～75°C | SP064GIMDA3K5EV0 |
| 128GB | -20～75°C | SP128GIMDA3K5EV0 |
| 256GB | -20～75°C | SP256GIMDA3K5EV0 |
| 512GB | -20～75°C | SP512GIMDA3K5EV0 |
