SPECIFICATIONS
Overview
Interface
SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
32GB ~ 512GB
Form Factor
Half Slim (MO-297)
Dimensions
54.0 x 39.0 x 4.0 mm
External DRAM Buffer
No
Performance
Seq. Performance Read (max.)
560MB/s
Seq. Performance Write (max.)
510 MB/s
Random 4K Read (IOPS max.)
91,000
Random 4K Write (IOPS max.)
81,000
MTBF @ 25°C
>3,000,000 hrs
P/E Cycle
60,000
TBW
512GB: 20,243 TB
256GB: 7,374 TB
128GB: 3,687 TB
64GB: 1,844 TB
32GB: 897 TB
256GB: 7,374 TB
128GB: 3,687 TB
64GB: 1,844 TB
32GB: 897 TB
Operating Environment
Operating Temperature
-40°C～85°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95% (30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Operation (max.)
480 mA
Power Idle / Standby
80 mA
Key Features
Advanced Power Shield
●
AES-256
●
Thermal Throttling
●
DEVSLP
●
S.M.A.R.T
●
DAP
●
FWxpress
●
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 32GB | -40°C～85°C | SP032GIHSD5M5EW0 |
| 64GB | -40℃ ~ 85℃ | SP064GIHSD5M5EW0 |
| 128GB | -40°C～85°C | SP128GIHSD5M5EW0 |
| 256GB | -40℃ ~ 85℃ | SP256GIHSD5M5EW0 |
| 512GB | -40°C～85°C | SP512GIHSD5M5EW0 |
