SPECIFICATIONS
Overview
Interface
CFast 2.0/SATA III/6.0Gbps
Flash Technology
3D TLC
Capacity
120GB～960GB
Form Factor
CFast
Dimensions
36.4 x 42.8 x 3.6 mm
Performance
Seq. Performance Read (max.)
520 MB/s
Seq. Performance Write (max.)
420 MB/s
Random 4K Read (IOPS max.)
55,000
Random 4K Write (IOPS max.)
65,000
MTBF
>3,000,000 hrs
P/E Cycle
3,000
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
320 mA
Power Consumption (idle)
140 mA
Key Features
Advanced Power Shield
●
DEVSLP/ TRIM
●
S.M.A.R.T
●
AES-256
●
Write Protect
◎
Thermal Throttling
●
Warranty
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 120GB | -20℃ ~ 75℃ | SP120GICFX3M5NV0 |
| 120GB | -20℃ ~ 75℃ | SP120GICFX3M5NVP |
| 240GB | -20℃ ~ 75℃ | SP240GICFX3M5NV0 |
| 240GB | -40℃～85°C | SP240GICFX3M5NW0 |
| 480GB | -20℃ ~ 75℃ | SP480GICFX3M5NV0 |
