SPECIFICATIONS
Overview
Interface
CFast 2.0/SATA III/6.0Gbps
Flash Technology
MLC
Capacity
8GB～512GB
Form Factor
CFast
Dimensions
36.4 x 42.8 x 3.6 mm
Performance
Seq. Performance Read (max.)
530 MB/s
Seq. Performance Write (max.)
330 MB/s
Random 4K Read (IOPS max.)
32,000
Random 4K Write (IOPS max.)
32,000
MTBF
>3,000,000 hrs
P/E Cycle
3,000
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V
Power Consumption (max.)
710 mA
Power Consumption (idle)
120 mA
Key Features
Advanced Power Shield
●
DEVSLP/ TRIM
●
S.M.A.R.T
●
AES-256
●
Write Protect
◎
Thermal Throttling
●
Warranty
Warranty
3 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 16GB | -20℃ ~ 75℃ | SP016GICFX315NV0 |
| 16GB | -20℃ ~ 75℃ | SP016GICFX315NVP |
| 32GB | -20℃ ~ 75℃ | SP032GICFX315NV0 |
| 32GB | -20℃ ~ 75℃ | SP032GICFX315NVP |
| 64GB | -20℃ ~ 75℃ | SP064GICFX315NV0 |
| 64GB | -20℃ ~ 75℃ | SP064GICFX315NVP |
| 128GB | -20℃ ~ 75℃ | SP128GICFX315NV0 |
| 256GB | -20℃ ~ 75℃ | SP256GICFX315NV0 |
