SPECIFICATIONS
Overview
Interface
CF 6.0
Flash Technology
SLC
Capacity
512MB～64GB
Form Factor
CF Card
Dimensions
42.8 x 36.4 x 3.3 mm
Performance
Seq. Performance Read (max.)
65 MB/s
Seq. Performance Write (max.)
54 MB/s
MTBF
>3,000,000 hrs
P/E Cycle
60,000
Operating Environment
Operating Temperature
-40°C～85°C / -20°C～75°C
CFI000V7/ CFI000W7
CFI000V7/ CFI000W7
Storage Temperature
-55°C～95°C
Operating Humidity
10%～95%
(30°C Max. Wet Bulb Temp)
(30°C Max. Wet Bulb Temp)
Vibration
20G, 10～2000Hz
Drop
75cm
Shock
1,500G@0.5ms
Power Consumption
Power Requirement
DC 3.3V or DC 5.0V
Power Consumption (max.)
180 mA
Power Consumption (idle)
0.5 mA
Key Features
S.M.A.R.T
●
Write Protect
◎
Warranty
Warranty
5 years within TBW
ORDER INFORMATION
| Capacity | Temp | P/N |
|---|---|---|
| 256MB | -20 ~ 75℃ | SP256MBCFI000V712T |
| 512MB | -20 ~ 75℃ | SP512MBCFI000V711T |
| 1GB | -20 ~ 75℃ | SP001GBCFI000V711T |
| 2GB | -20 ~ 75℃ | SP002GBCFI000V711T |
| 4GB | -20 ~ 75℃ | SP004GBCFI000V711T |
| 8GB | -20 ~ 75℃ | SP008GBCFI000V712T |
| 16GB | -20 ~ 75℃ | SP016GBCFI000V714T |
| 32GB | -20 ~ 75℃ | SP032GBCFI000V714T |
| 64GB | -20 ~ 75℃ | SP064GBCFI000V714T |
| 512MB | -40 ~ 85℃ | SP512MBCFI000W711T |
| 1GB | -40 ~ 85℃ | SP001GBCFI000W711T |
| 2GB | -40 ~ 85℃ | SP002GBCFI000W712T |
| 4GB | -40 ~ 85℃ | SP004GBCFI000W714T |
| 8GB | -40 ~ 85℃ | SP008GBCFI000W712T |
| 16GB | -40 ~ 85℃ | SP016GBCFI000W714T |
| 32GB | -40 ~ 85℃ | SP032GBCFI000W714T |
| 64GB | -40 ~ 85℃ | SP064GBCFI000W714T |
